Fit Aid Commercial Strip Heater – Single Group

Fit Aid Commercial Strip Heater – Single Group

Seamless Integration & Ultra-Thin Architecture Featuring an ultra-thin 152mm width profile, this single-element heater can be discreetly concealed beneath pick-up windows or prep tables without disrupting the overall decor. Built with ...

Explore Our Kitchen Projects

Introduction
Download Center
More Products

Introduction

Seamless Integration & Ultra-Thin

Architecture Featuring an ultra-thin 152mm width profile, this single-element heater can be discreetly concealed beneath pick-up windows or prep tables without disrupting the overall decor. Built with industrial-grade durability, the housing is constructed from heavy-duty 1.2mm AISI 304 stainless steel, ensuring it effortlessly withstands the busiest service peaks.

3. Strip Heater EGO Temperature Control.jpg

Precision Heating & Incoloy 840 Elements

Performance is driven by a long-lasting Incoloy 840 dry-burning infrared heating element that eliminates heating blind spots. Temperature is managed by a premium German E.G.O thermostat, providing precise and effortless heat adjustments. The intelligent natural convection cooling design protects internal components, significantly extending the unit's lifespan.

Modular Customization & Uncompromised Safety

Safety is paramount in any commercial environment. This unit features UL-certified high-temperature wiring and ceramic sockets, along with clear power and operation indicator lights for easy monitoring. With 9 customizable length options ranging from 24 to 72 inches and optional sneeze guards and mounting brackets, it provides a complete and versatile pass-through solution.

Key Features & Common Specifications

General Specifications	Details
Housing Material	Heavy-duty 1.2mm AISI 304 stainless steel
Heating Element	Incoloy 840 dry-burning infrared element
Thermostat	Premium German E.G.O thermostat
Wiring	UL-certified high-temperature wiring and ceramic sockets
Features	Power and operation indicator lights, Natural convection cooling
Color Options	Standard Stainless, Gunmetal Grey, Black
Optional Accessories	Sneeze Guard (C), Bracket (B)

Model Specifications (Single Group)

Model Number	Dimensions (L x W x H mm)	Voltage	Power (W)
SH/24H	610 x 152 x 68	220-240V/50-60Hz	500
SH/30H	760 x 152 x 68	220-240V/50-60Hz	650
SH/36H	915 x 152 x 68	220-240V/50-60Hz	800
SH/42H	1068 x 152 x 68	220-240V/50-60Hz	950
SH/48H	1220 x 152 x 68	220-240V/50-60Hz	1100
SH/54H	1370 x 152 x 68	220-240V/50-60Hz	1250
SH/60H	1525 x 152 x 68	220-240V/50-60Hz	1400
SH/66H	1678 x 152 x 68	220-240V/50-60Hz	1520
SH/72H	1830 x 152 x 68	220-240V/50-60Hz	1700

Engineered for High-Volume Pass-Throughs

The Single Group Strip Heater is the system of choice for uncompromising culinary environments.

✓ High-Volume Kitchen Pass-Throughs

✓ Buffet Carving & Serving Stations

✓ Quick Service Restaurant Pick-up Counters

✓ Open Kitchen Prep Tables

3. The Benchmark for Global Excellence Fit Aid.jpg

FAQ

Q1: Are you a direct factory or a trading company?

A: We are a comprehensive commercial kitchen engineering contractor. We operate our own manufacturing facilities (specializing in custom stainless steel and heating equipment) AND serve as an authorized distributor for 40+ top international brands. This allows us to provide unbiased, optimized, and tailored equipment combinations for your project.

Q2: What is exactly included in your "A-Z Turnkey Solution"?

A: We handle everything from the ground up. You provide the floor plan, and we deliver a fully operational kitchen. Our services include:

l 2D/3D kitchen layout design & MEP consulting

l Custom manufacturing & equipment procurement

l Global logistics & online/onsite installation guidance

Q3: How do you guarantee the quality of international projects?

A: Quality is our baseline. Our self-manufactured equipment utilizes world-class components (e.g., German thermostats, imported IGBT modules). Furthermore, every single piece of equipment—whether built by us or sourced—undergoes a rigorous unified pre-shipment inspection by our engineering QA team before container loading.

Q4: What is the typical lead time for a complete kitchen project?

A: For a complete A-Z project, the production and consolidation timeline typically ranges from 4 to 6 weeks after the final layout and equipment list are approved. We provide strict project timelines to ensure your facility opens on schedule.

Q5: How do you handle warranty and after-sales service overseas?

A: We provide a 1-year warranty on core components. Understanding the distance, we proactively include a package of essential vulnerable spare parts with your initial shipment. Additionally, our technical support team offers 24/7 online troubleshooting and video guidance to ensure zero downtime.

Download Center

Resources & MEP Specifications

For consultants, contractors, and kitchen designers.

[Download Strip Heater Spec Sheet (PDF) ]

Fit Aid Commercial Strip Heater – Single Group.pdf

[Request CAD Drawings / 3D BIM Models]

[Download Installation & Maintenance Manual]
